JSX2024ITC
12460*2500*3980/mm
25000L
| imension of the 40FT 40.44CBM LNG Tank Container with BV&T75 | ||||||
| Description and Specification of Commodity | ||||||
| Codes and regulations for tank container | TSG R0005-2011 | |||||
| Guidelines for tank container | T75 | |||||
| Container Type for tank container | 1AA | |||||
| Rated weight for tank container | 32723kgs | |||||
| Maximum Allowed Loading Weight for tank container | 14700kgs | |||||
| Tare weight for tank container | 18023kgs | |||||
| Allowed stacking weight for tank container | 192000kgs | |||||
| Manufacturing license level for tank container | Inside tank | C3 | ||||
| outside tank | ||||||
| Overall Size(Frame)/L*W*H/mm for this storage tank | 12192*2438*2591 | |||||
| Media for this storage tank | Inside tank | LNG | ||||
| Media Characteristics for this storage tank | Inside tank | explosive | ||||
| Paint for this storage tank | Frame | 30µm +40µm +50µm | ||||
| Shell | 30µm +40µm +50µm | |||||
| Total Volume(L) for this storage tank | 40440 | |||||
| Effective volume(L) for this storage tank | 36400 | |||||
| Material density(kg/m3) for this storage tank | Inside tank | 426 | ||||
| Natural boost rate for this storage tank | Inside tank | <=13 | ||||
| Main hazard category for this storage tank | 2.1 | |||||
| Design service life for this storage tank | 15 years | |||||
| Mode of transportation for this storage tank | Road,Sea or Railway | |||||
Adiabatic form for this storage tank | High vacuum multilayer insulation | |||||
FlEXIBLE SERVICE WE PROMISED FOR EACH ITEM FROM OUR FACTORY:
>>>Offering the one-stop full lifecycle services;
>>>Our vehicle users will receive 24-hour uninterruptible "Entire Journey" service;
>>>CCC&ISO Agreement, 1 Year Guarantee Term, Main-beam Lifetime Promise;
>>> Small Order Can Be Accepted;
>>>Any Color & Logo Available;
>>>The Product Dimension + Specifications Can Be Designed As Your Needs.
Buying Guides for this ISO Storage Tank Container
**You please send us your enquiry;
**We shall reply you with the quotation within 12 hours;
**We negotiate on the configuration that you need;
**Confirmation of the tech data → sign contract (P/I) → 30% deposit (or L/C issuing)→ production;
**Manufacturing process updated news → completing production;
**Balance payment → ex works → shipment → custom clearance → A/S service for 1 year.
