Availability: | |
---|---|
Quantity: | |
JSX9217GTC
12460*2500*3980/mm
21700L
Description and Specification of Commodity | ||||||
Loading Capacity | 22tons | |||||
Overall Size | 6058*2438*2591/mm | |||||
Compartment | Single | |||||
Painting | Complete chassis sand blasting to clean rust,1 coat of anti-corrosive prime,2 coats of final paint. | |||||
Design data sheet | ||||||
Code and Regulations | ASME BOILER AND PRESSURE VESSEL CODE,SECT.VIII. DIV.2 WITH U2-STAM RID/ADR,IMDG T50,UIC,CSC,TC,TIR/CCC,ISO 1496/3 | |||||
DESIGN PRESSURE(MPa) | 1.52 | PRESSURE-RETAINING PARTS | Shell | SA-612M NORMALIZED | ||
MAWP,acc IMDG(MPa) | 1.38 | Heads | SA-612M NORMALIZED | |||
MEAWP(MPa) | 0.1 | EXTERNAL DEMENSIONS(L/W/H) | 6058/2438/2591 | |||
DESIGN TEMPERATURE(ºC) | 55 | INSULATION OR SUN SHIELD | SUN SHIELD | |||
OPERATING TEMPERATURE(ºC) | -40~50 | Paint | Frame | 30μm+40μm+50μm | ||
MDMT(ºC) | -40 | Shell | 30μm+40μm+50μm | |||
NOMINAL VOLUME(L) | 21700 | MAX. GROSS MASS (KG) | 35000 | |||
FILLING MEDIUM | 1,1,1,2-Tetrafluoroethane | TARE MASS (KG) | 6800 | |||
MEDIUM UN NUMBER | UN3159 | MAX. FILLING DENSITY (t/m 3 ) | 1.04 | |||
TANK INSTRUCTION | T50 | MAX. PAYLOAD (KG) | 22568 | |||
CORROSION ALLOWANCE(mm) | 0 | JOINT EFFICIENCY(SHELL/HEAD) | 1 | |||
PWHT(YES/NO) | YES | TEST | HYDRO.TEST PRESSURE(MPa) | 2.18 | ||
U2 STAMP | YES | LEAKAGE TEST PRESSURE(MPa) | 1.38 | |||
INSPECTION AUTHORITY | BV/TUV | N/A | N/A |
FlEXIBLE SERVICE WE PROMISED FOR EACH ITEM FROM OUR FACTORY:
>>>Offering the one-stop full lifecycle services;
>>>Our vehicle users will receive 24-hour uninterruptible "Entire Journey" service;
>>>CCC&ISO Agreement, 1 Year Guarantee Term, Main-beam Lifetime Promise;
>>> Small Order Can Be Accepted;
>>>Any Color & Logo Available;
>>>The Product Dimension + Specifications Can Be Designed As Your Needs.
Buying Guides for this ISO Storage Tank Container
**You please send us your enquiry;
**We shall reply you with the quotation within 12 hours;
**We negotiate on the configuration that you need;
**Confirmation of the tech data → sign contract (P/I) → 30% deposit (or L/C issuing)→ production;
**Manufacturing process updated news → completing production;
**Balance payment → ex works → shipment → custom clearance → A/S service for 1 year.
Contact information for this storage tank container
