JSXT03225
JSXT
8705909990
9200×2580×3700
10 ton
Trucks Features :
1. The truck can work under a temperature from 41C to + 46C day and night, elevation up to 5000m high. The options for the truck are ABS system, concentrated lubricating system, hydraulic windlass, etc.
2. The cab of dongfeng series off-road vehicle is four-point suspended and installed the domestic originally created horizontal stabilizer for cab as well as strong protector frame to prevent front striking Thus the cab has been thought of the safest domestic cab by specialists.
3. Equipped with such advanced parts asEuro-lI/ Euro lll turbine turbocharged inter-cooled CUMMINS diesel engines, power ranging from 266hp to 300hp, FAST transmission, strengthened drive axle, WABCO brake system
| Vehicle Main Dimensions | Overall dimensions (L x W x H) mm | 9200×2580×3700 |
| Carriage Size (L x W x H) mm | 5900×2300×600 | |
| Wheel base (mm) | 5200 | |
| Wheel track (front/rear) (mm) | 1886/1845 | |
| Weight in KGS | Tare Weight | 6900 |
| payload | 10000 | |
| Front axles loading capacity | 1x3600 | |
| Rear axles loading capacity | 1x10500 | |
| Max. driving speed(km/h) | 95 | |
| Engine | Brand | DF/Shacman/sinotruck |
| Model | YUCHAI | |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Horse Power(HP) | 160 | |
| Emission standard | Euro II | |
| Gearbox | WLY 6 Forwards gear & 1 reverse gear | |
| Clutch | Reinforced diaphragm clutch, diameter 430 mm | |
| Tire | 9.00R20 Radial tyre 7pcs including one spare tire | |
| Crane specifications | Type: Telescopic | |
| Max lift capacity: 4000 kg | ||
| Max lifting height when Fully extended: 9420mm | ||
Our Advantages
1) Favorable price: Factory price, very competitive in the market.
2) In time Warranty: One year or 100,000km for on road trucks as tractor truck or 6 months or 60,000km for off road trucks as dump truck, which comes to the first for the engine, gear box, and axles. We have offices in Tanzania, Zambia and Philippines to provide warranty service, and we have distributors in different countries all over the world to assist.
3) In time After-sales: We have set up over 240 spare parts centers and service outlets all over 80 countries, professional after-sales team solve your after sales problem within 3 working days or 5 working days, and all spare parts are available for you.
4) Experienced sales team and logistics team: Experienced sales team are at your service all the time and offer excellent service, professional logistics team work with international shipping company such as MSK&Hyundai to ship your trucks safely and cost-efficiently.
Trucks Features :
1. The truck can work under a temperature from 41C to + 46C day and night, elevation up to 5000m high. The options for the truck are ABS system, concentrated lubricating system, hydraulic windlass, etc.
2. The cab of dongfeng series off-road vehicle is four-point suspended and installed the domestic originally created horizontal stabilizer for cab as well as strong protector frame to prevent front striking Thus the cab has been thought of the safest domestic cab by specialists.
3. Equipped with such advanced parts asEuro-lI/ Euro lll turbine turbocharged inter-cooled CUMMINS diesel engines, power ranging from 266hp to 300hp, FAST transmission, strengthened drive axle, WABCO brake system
| Vehicle Main Dimensions | Overall dimensions (L x W x H) mm | 9200×2580×3700 |
| Carriage Size (L x W x H) mm | 5900×2300×600 | |
| Wheel base (mm) | 5200 | |
| Wheel track (front/rear) (mm) | 1886/1845 | |
| Weight in KGS | Tare Weight | 6900 |
| payload | 10000 | |
| Front axles loading capacity | 1x3600 | |
| Rear axles loading capacity | 1x10500 | |
| Max. driving speed(km/h) | 95 | |
| Engine | Brand | DF/Shacman/sinotruck |
| Model | YUCHAI | |
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | |
| Horse Power(HP) | 160 | |
| Emission standard | Euro II | |
| Gearbox | WLY 6 Forwards gear & 1 reverse gear | |
| Clutch | Reinforced diaphragm clutch, diameter 430 mm | |
| Tire | 9.00R20 Radial tyre 7pcs including one spare tire | |
| Crane specifications | Type: Telescopic | |
| Max lift capacity: 4000 kg | ||
| Max lifting height when Fully extended: 9420mm | ||
Our Advantages
1) Favorable price: Factory price, very competitive in the market.
2) In time Warranty: One year or 100,000km for on road trucks as tractor truck or 6 months or 60,000km for off road trucks as dump truck, which comes to the first for the engine, gear box, and axles. We have offices in Tanzania, Zambia and Philippines to provide warranty service, and we have distributors in different countries all over the world to assist.
3) In time After-sales: We have set up over 240 spare parts centers and service outlets all over 80 countries, professional after-sales team solve your after sales problem within 3 working days or 5 working days, and all spare parts are available for you.
4) Experienced sales team and logistics team: Experienced sales team are at your service all the time and offer excellent service, professional logistics team work with international shipping company such as MSK&Hyundai to ship your trucks safely and cost-efficiently.
