4 Axle 70T Heavy Truck Container Truck Semi Trailer

Axle: 4
Tire: 12R22.5
Loading Capacity: 70 T
Size: 13000*2600*1600 mm
Availability:
Quantity:
  • JSX114570FBT

  • 13000*2600*1600 mm

  • 70 Tons

Product-Concept

container truck flat bed semi trailer 13

Product-Features

1.Steel frames are built with top-class hot rolled or rolled steel plate, automatic welded longitudinal beam and adopting advanced sanding and painting process as preliminary treatment.

2.Different types of suspension are designed for various operating condition: Bogie suspension; Air suspension; Mechanical suspension.

3.Lamp assembly uses advanced LED light, top quality PC and cast wire harness in dual circuit design.

4.Automatic tire inflation and pressure sensor system is optionally available for enhanced safety and better fuel economy.

5.State-of-the-art detection devices: Components, hardness, and phase of metal are analyzed to ensure the standards of processed material; Weld seam defects, paint thickness and adhesuveness are checked and amended to guarantee the quality of finished products.

Standard-Parameter

Parameters of Semi Trailer
Product Name 4 Axle 70T Semi Trailer Product Code JSX114570FBT
Tare Weight 7200kg Loading Capacity 70T
Outside Dimension 13000*2600*1600mm Wheelbase 6800+1310+1310+1310mm
Axle Amount 4 Pieces of leaf-spring 14
Suspension Heavy Duty Leaf Spring  Color and Logo Optional and customized
Tyre Amount 16 +1(Spare Tyre) Tyre Specifications 12R22.5
Main Beams  Q345B/ST52-3 Cross Beams  Q235
Main Beams Height 500mm Upper Flange 16mm
Mid web 8mm Lower Flange 12mm
Side Beam 165mm Brake System Dual-pipes braking system/ABS
rake Chamber Front two axle is 35 air chamber Electrical System 24V, 7core socket
Tool Box Optional Spare Tyre Carrier 2
Side beam Channel steel King Pin 50# or 90#

[TIP: The above parameters are just general configuration.If you have specific requirements, such as flatbed/skeleton trailer style, total load, axle structure, and even important parts, we can customize it for you.]

Structure-and-Principle

container truck flat bed semi trailer 30

1.Compared with "monomer" cars, semi-trailer can improve the comprehensive economic benefits of road transportation.The transportation efficiency can be increased by 30-50%, the cost is reduced by 30-40%, and the oil consumption decreases by 20-30%.

2.The frame is the beam type structure, the longitudinal beam adopts flat or gooseneck.The height of the web is from 400mm to 550mm, the longitudinal beam adopts automatic submerged arc welding, the frame adopts the shot blasting treatment, the beam is put into the longitudinal beam and welding the whole.

3.The structure is reasonable by using the tandem type dry plate spring and suspension support.It has strong rigidity and strength, which is used to support load buffer.

4.The semi-trailer walking structure uses high strength international steel, the vehicle is light weight, and guarantees the anti-distortion, anti-seismic and anti-turbulence ability, and meets different pavement and carrying capacity.

Product-Details

Container Truck Semi Trailer 3

Container Truck Semi Trailer 1

About the details for Container Semi Trailer:

In order to produce a high quality product, the details are very important.The important parts we use, such as,car axle, brake system, shock absorber system, even steel plate.are well-known brands in China and even the world.

Packing-&-Shipping

Container-Truck-Semi-Trailer-5

About the packing for Container Semi Trailer:

We'll try to help you save transportation costs.We have been in contact with many customers, so we have a very good ways for product transportation.
